Inficon XTC/3 User Manual

2 - 9
XTC/3 Operating Manual
2.3.3.2.1 System I/O Connector
Table 2-1 System I/O connector
Description Pin # XTC/3S Function
Relay 1 1, 2 Source Shutter 1
Relay 2 3, 4 Source Shutter 2
Relay 3 5, 6 ** Sensor Shutter 1
Relay 4 7, 8 ** Sensor Shutter 2
Relay 5 9, 10 Stop
Relay 6 11, 12 End of Process
Input 1 18 Start
Input 2 19 Stop
Input 3 20 End deposit
Input 4 21
*
Sample Initiate
Input 5 22
*
Sample Inhibit
Input 6 23
*
Crystal Fail Inhibit
Input 7 24
*
Zero thickness
Input 8 25
*
Soak 2 Hold
Ground 13,14,15,16,17 Input Common
* These input functions may be reassigned according toTable 2-2.
** Used for Crystal Switching for a XTC/3S.
Table 2-2 Film Select Option selected in XTC/3S General / Process screen
Input # Pin # Function Description
421RESET
pin22 pin23 pin24 pin25 Film #
522Film Select MSB
000X1
623Film Select
00102
724Film Select
00113
825Film Select LSB
01004
01015
01106
01117
10008
10019
1X1X1
X = Does not matter
