2 - 2
XTC/3 Operating Manual
2.1.2 Sensor Installation
Figure 2-1
shows a typical installation of an INFICON water cooled cryst
al sensor
in the vacuum process
chamber
. Use the illu
stration
and the following guidelines to
install sensors for op
timum performance
and convenience.
Figure 2-1 T
ypical installation
>
Mounting Brackett
Coax Cable
(Routed with
water tubes)
Braze/Weld Joint
or Compression Fittings
Source to Sensor
(10 in. Minimum)
Sensor
Shutter
Source
Pneumatic
Actuator
IPN 750-420-G1
Solenoid
V
alve
Instrument Chassis
To
Source Controller
XIU (Oscillator)
To
Sensor
Shutter
W
ater In
W
ater Out
Air Supply
Source
Shutter
29
31
