TLE5012B
SSC Registers
User’s Manual 100 Rev. 1.2, 2018-02
T_RAW Register
T_RAW Offset Reset Value
T_RAW Register 15
H
0000
H
Field Bits Type Description
T_TGL 15 ru Temperature Sensor Raw-Value Toggle
Toggles after every new temperature value (T_RAW).
Reset: 0
B
T_RAW 9:0 ru Temperature Sensor Raw-Value
Temperature at ADC. This value is not compensated with
the offset temperature. T_RAW range is not limited as
TEMPER. T_RAW is an unsigned value.
T[°C]=(T_RAW[dig]-369[dig]-T25O[dig]) / 2.776[dig/°C]
Reset: 0
H
15 8
7 0
1515
ru
T_TGL
14 13 1212 1111 1010 99
ru
T_RAW
88
77665544
ru
332211 00
T_RAW
Res
