Infineon Technologies TLE5012B - Page 101

TLE5012B
SSC Registers
User’s Manual 101 Rev. 1.2, 2018-02
Increment Counter Register
Temperature 25°C offset value
IIF_CNT Offset Reset Value
IIF Counter value 20
H
0000
H
Field Bits Type Description
IIF_CNT 13:0 ru Counter value of increments
Internal 14-bit counter for the incremental interface,
which counts from 0 to 16383 during one full turn.
It can be used for synchronization purposes between
sensor and counter value on microcontroller side.
Therefore, depending on the setting of the IFAB_RES
register (9bit to 12bit resolution of incremental interface),
2 to 5 LSBs have to be removed from IIF_CNT for the
synchronization.
Reset: 0
H
T25O Offset Reset Value
Temperature 25°C Offset value 30
H
device-specific
Field Bits Type Description
T25O 15:9 r Temperature 25°C Offset value
Signed offset value at 25°C temperature; 1dig=0.36°C.
T25O = T_RAW(@25°C)[dig]-439[dig].
Reset: device-specific
15 015 14
Res
13 0
ru
IIF_CNT
15 8
7 0
1515
r
14 13 1212 1111 1010 99
r
Res
88
77665544332211 00
T25O
Res
