User Manual for the Thermographic System VarioCAM
®
high resolution
3. Technical Description
User Manual © InfraTec GmbH 2013 9
3.3 Technical Data
Spectral range (7.5 ... 14) µm
Temperature measuring range (-40 ... 1,200) °C, optional > 2,000 °C
Temperature resolution @ 30 °C better than 0.08 K, up to 0.05 K (premium mode)
Measurement accuracy ± 1.5 K (0 ... 100) °C; ± 2 % (< 0 and > 100) °C
Emissivity Adjustable from 0.1 to 1.0, in increments of 0.01
Recording, image format (pixels) Focal Plane Array , (320 x 240) or
(384 x 288), Resolution Enhancement onto (768 x 576)
(640 x 480), Resolution Enhancement onto (1,280 x 960)
Detector uncooled microbolometer Focal Plane Array
IR frame rate 50/60 Hz
Standard lens (field of view) 1.0/25 mm (25 x 19)° at (320 x 240)
1.0/25 mm (30 x 23)° at (384 x 288)
1.0/30 mm (30 x 23)° at (640 x 480)
Zoom function Up to 8 times digital, infinitely variable
A/D conversion 16 bit
Image memory SD card, FireWire (IEEE 1394) up to 50/60 Hz,
internal real-time storage
Voice and text annotation image-integrated
Interfaces PAL/NTSC-FBAS, S Video, VGA, RS232, WLAN
FireWire (IEEE 1394), Headset
Integrated digital colour video camera 1.3 megapixels, video LED
Power supply Lithium-ion battery, mains adapter, FireWire (IEEE 1394)
Battery system Lithium-ion, quickly rechargeable, with status display, mains and car
recharging unit
Operating time with battery up to approx. 3 h
Operation temperature (-15 ... 50) °C
Storage temperature (- 40 ... 70) °C
Humidity during operation and storage relative humidity 5 % to 95 %, non-condensing
Dimensions (complete system) (133 x 106 x 110) mm
Weight (complete system) approx. 1.5 kg
Tripod recepticle 1/4" screw thread
Warning: observe max. screw-in depth of 4.5 mm!
(DIN 4503)
Display daylight-suited digital 3.5" active colour TFT display
Viewfinder integrated high resolution colour TFT viewfinder with dioptric
adjustment
Controls 4-key multifunctional joystick
Laser red semiconductor laser, laser protection class 2
Display functions thermogram, operator-guided, menu, results, status
Measurement functions max. 10 freely selectable ROI, auto hot/cold spot display, isotherms
Automatic functions autofocus, autoimage, autolevel, autorange, alarm,
auto NUC, auto lens recognition, premium snap, sequence saving,
resolution enhancement
Protection class in operation IP 54, IEC 529
Shock resistance 25 G, IEC 68-2-29
Vibration resistance in operation 2 G, IEC 68-2-6
* (Properties and technical specifications are dependent on the camera configuration and vary in the equipment packages VarioCAM
®
hr basic, inspect and research.
Design and specifications are subject to permanent improvement; subject to changes in the sense of technical progress.)
