User Manual for the Thermographic System VarioCAM
®
high resolution
7. Starting up
16 © InfraTec GmbH 2013 User Manual
7 Starting up
7.1 Shoulder Strap Adjustment
How to fix the shoulder strap is explained in the following figures:
Fig. 10 Step 1:
The lace is to be pulled through
the flap at the back of the
camera by approx. 10 cm from
the top.
Fig. 11 Step 2: Fig. 12 Step 3:
The loose end of the lace is pulled through the sleeve which then is
pressed against the flap of the camera.
Fig. 13 Step 4:
The longer side of the lace is to
be loosened at the fastener.
Fig. 14 Step 5:
Then the short side of the lace
is also pulled through the
fastener and tightened, so that
only one flap is to be seen.
Fig. 15 Last step:
The long, upper side of the lace is
pulled through the fastener and
tightened, so that no flap is to be
seen any longer.
The loose end of the strap should always show ≥ 5 cm beyond the fastener!
