InHand VG710 InVehicle Gateway User Manual
48
2. Networking diagram
Gateway
Ethernet port
connected to host A
IP address of the port
connected to host A
Priority Work mode
VG710_A bridge 1 10.5.16.80 110 Preemption
VG710_B bridge 1 10.5.16.81 100 Preemption
Method for settings when VG710_A acts as the master gateway and VG710_B as a backup
gateway:
1. Configure VG710_A.
Click "Link Backup >> VRRP", set "Virtual Route ID" as required, select the gateway interface of
VG710_A, enter the virtual IP address, set the interface priority to 110, and click Add.
In the navigation tree, click "Link Backup >> VRRP >> Status" and view the VRRP status.
