InHand VG710 InVehicle Gateway User Manual
40
5.6 Routing
5.6.1 Static Routing
Set the destination network, subnet mask, and interface or gateway as required.
5.6.2 Dynamic Routing
Scenario: Enable dynamic routing between two LANs for mutual communication between them. The
topology is shown below.
