9.7.3 SnmpMibs
In SNMP messages, management variables are used to describe the managed objects on the device. To
uniquely identify the managed objects on the device, SNMP uses a hierarchical naming scheme to
identify the managed objects The entire hierarchical structure is like a tree. The nodes of the tree
represent the managed objects, as shown in the figure below. Each node can be uniquely identified by
a path starting from the root.
The management information base (MIB) is used to describe the hierarchical structure of the tree. It is
a set of standard variable definitions for the monitored network device. In the above figure, managed
object B can be uniquely determined based on a string of numbers {1.2.1.1}, which form the object
identifier (OID) of the managed object.
Method for downloading a SnmpMibs file to the PC via the gateway:
Click "Administration >> SNMP >> SnmpMibs", select a folder, and click download to download it to
the PC. Find the folder on the PC and import it to the NMS.
