page 26 innovaphone IP DECT
4.1.2.3 Configuration/IP/H.323 NAT
H.323 NAT is an add-on for the general NAT function. This function is only nee-
ded if the telephone connects the private network with the public network. The
telephone must therefore represent a connecting point between the two net-
works. This function enables H.323 calls between private and public networks.
The Status section provides you with a brief overview of the registered users
(Registered Clients) and the calls currently active (Active Calls).
4.1.2.4 Configuration/IP/PPP Config
The parameters for the DSL and VPN connections are set here.
Clicking the interface ID (PPPn) opens the respective configuration page, on
which the PPP interface configuration can be performed.
PPP Interface PPP
n
section:
Enable
H.323 NAT
Enables NAT for H.323 VoIP calls.
Require
authentica-
tion
H.323 authentication is obligatory if the check box is checked.
This setting protects against externals attacks on the private
network. H.323 messages without authentication are not rou-
ted to the private network.
H.225/RAS
destination
IP address of the server in the private network, to which inco-
ming H.225/RAS messages are routed.
H.225/
Signalling
destination
IP address of the server in the private network, to which inco-
ming H.225/signalling messages are routed.
Enable Enables/disables the interface. The PPP interface is only dis-
played in the PPP State overview page if it is enabled.
Connection
Port
For PPP connections using ISDN channels, you select one of
the ISDN interfaces (PPP, TEL
,
BRI, PRI) here. This concerns
only devices with an ISDN interface. However, PPTP (VPN)
and PPPoE (DSL) connections using the Ethernet interface
(ETH) are also possible.
Descriptive
Name
A descriptive name for the interface can be entered here.
This name is used for the overview in the PPP State submenu
(see chapter entitled “
Configuration/IP/PPP State
”).
