innovaphone IP DECT Page 67
Subscriber B:
4.2.2 Administration/Gateway
The gateway configuration of the device can be performed here. The Gateway
menu establishes the connection to the conventional telephone network, for ex-
ample, via a digital ISDN interface or a VoIP interface. Depending on which de-
vice is used, various interfaces are available. They include the virtual TEST, TONE
and HTTP interfaces, the analogue interfaces (TEL), as well as the ISDN inter-
faces (TEL, PPP, BRI or PRI). With the use of additional licences, so-called VoIP
interfaces (GW1-12) are also available, which enable the linking of PBXs without
using the innovaphone PBX, for example.
Media Display of the coder used on the calling side, for example,
G711AB(2,0,0).
The values in
brackets have the following
meaning, in order:
Round trip (RT) = Transit time of a data packet from A to B
and back again.
Jitter = Latency time (time interval from the end of an event
up to the start of the response).
Loss (PL) = Number of lost packets (packet loss).
Dir In the
Alerting
state “>” and in the
Connected
state “>>”.
Number Display of the called number.
Name Display of the called name.
Protocol Display of the protocol used on the called side.
Media Display of the coder used on the called side.
State Possible states:
Alerting, Calling, Connected, Disconnecting
.
