innovaphone IP DECT Page 81
4.2.2.3.1 Interface (VoIP Interfaces)
Clicking the relevant VoIP interface (
GW1-12 <Name of the VoIP interface>
) in
the Interface column opens a popup page, on which the VoIP interfaces can be
individually configured. Like the PBX objects, this popup page also contains stan-
dard entry fields that occur, more or less, in all VoIP interfaces.
These standard fields are:
CGPN In, CDPN
In, CGPN Out,
CDPN Out
Precise details on CGPN In, CDPN In, CGPN Out and
CDPN Out mappings are contained in the chapter entitled
“
Administration/Gateway/Interfaces/CGPN-CDPN Map-
pings
” further up in the text.
Registration If a terminal has successfully registered with a gateway,
then this is indicated in this column through specification
of the IP address
<Name of the VoIP interface:Call num-
ber:IP address>
.
Name The descriptive name of the VoIP interface.
Disable A checked check box disables the relevant VoIP interface.
Protocol The protocol to be used, that is,
H.323
or
SIP
. Depending
on which protocol is used, the set-up of the entry fields
changes.
Mode Describes the mode of registration. Possible registration
modes are:
1. Gateway without Registration - Logs the VoIP interface
(gateway) on to the configured gatekeeper without a
registration.
2. Register as Endpoint - Registers a VoIP terminal with
the configured gatekeeper.
3. Register as Gateway - Registers a VoIP gateway with
the configured gatekeeper.
4. Gatekeeper/Registrar - Is required for managing all
gatekeeper registrations on a gateway.
5. ENUM - Is used to register an ENUM connection with
the relevant interface.
Gatekeeper
Address (pri-
mary)
The primary Gatekeeper IP address at which the terminal
or gateway is to register via the relevant interface. Only
necessary for modes 2 and 3 .
