4.2.2.6 Administration/Gateway/Calls
In the Calls gateway overview page, all calls actively being made can be moni-
tored. This is advantageous for diagnostic purposes in particular, since the exi-
stence of possible network problems, for example, is immediately visible (see
Coder):
HTTP The CDR entries are transferred to a Web server, where they
can be further processed. Each individual CDR entry is transfer-
red as form data to the Web server in HTTP GET format.
•In the Address field, you enter the IP address of the Web
server that carries out further processing of the transmit-
ted data.
•In the Path field, you enter the relative URL of the form
program on the Web server.
The device will make a HTTP GET request to the Web ser-
ver on the entered URL, followed by the URL-encoded CDR
entry. If, for example, a page named /cdr/cdr-
write.asp with a form that expects the log message in
parameter msg
exists on a Web server, then the value /
cdr/cdrwrite.asp is entered. The device will then
make a GET
/cdr/cdrwrite.asp?event=sys-
log&msg=logmsg request to the Web server.
Interfaces Display of the calling interface.
Protocol Display of the protocol used on the calling side.
Coders Display of the coder used on the calling side, for example,
G711AB(2,0,0). The values in brackets have the following
meaning, in order:
Round trip = Transit time of a data packet from A to B and
back again.
Jitter = Latency time (time interval from the end of an event
up to the start of the response).
Loss = Number of lost packets (packet loss).
Number Display of the called number.
State Possible states: Alerting, Calling, Connected, Disconnecting .
