innovaphone IP DECT Page 73
4.2.2.2 Administration/Gateway/Interfaces
The display of the gateway’s configurable interfaces is organised in columns:
4.2.2.2.1 Interface (ISDN, SIP & virtual interfaces)
Clicking the name of an interface in the Interface column opens a popup page,
on which the interfaces can be individually configured. Like the PBX objects, this
popup page also contains standard entry fields that occur, more or less, in all in-
terfaces. These standard fields are:
Interface The name of the interface. Clicking this name opens a
popup page, on which all settings can be made. The set-
tings are described in more detail in the following chap-
ter “
Administration/Gateway/Interfaces/Interface (ISDN
& virtual interfaces)
”.
CGPN In, CDPN
In, CGPN Out,
CDPN Out
Precise details on CGPN In, CDPN In, CGPN Out and
CDPN Out mappings are contained in the chapter entitled
“
Administration/Gateway/Interfaces/CGPN-CDPN Map-
pings
” further down in the text.
State The current state of the interface at physical and at pro-
tocol level. Possible states are:
Up, Down.
Registration If a terminal has successfully registered with an ISDN,
SIP or virtual interface, then this is indicated in this
column through specification of the
IP address<Name of
the VoIP interface:Call number:IP address>
.
Name The descriptive name of the interface.
Disable A checked check box disables the relevant interface.
Tones The standard calling tone for the relevant interface is set
with the Tones list box.
Interface Maps The interface can be configured as a point-to-point con-
nection (
Point-to-Point
), as a point-to-multipoint connec-
tion (
Point-to-Multipoint
) or manually (
Manual
) using
CGPN/CDPN maps.
See description further down in the text.
