way / Interfaces as follows:
In the example above, the trunk line of the SIP carrier sipgate.de is picked up
using the
Trunk PBX object with the name SIPTrunk and the call number 8 . The
dialling of the call number 807031730090 therefore initiates a call at innova-
phone AG via the configured SIP carrier.
Virtual interfaces (TEST, TONE, HTTP)
The non-configurable, internal interface TEST is only usable as the destination
for a call. If a call is received on this interface, the music on hold contained in
the non-volatile memory is played. Incoming calls must be in G.729A or G.723
format; other formats are not supported. Suffix dialling digits are ignored.
The internal interface TONE is only usable as the destination for a call. If a call
is received on this interface, it is connected and the configured dial tone (Tones)
is played. This happens particularly with least-cost-routing scenarios, where
the call can only be switched once some of the dialled digits have been analysed.
In the meantime, the dial tone is played via the TONE interface. Suffix dialling
digits are ignored. The TONE interface can process several calls.
The non-configurable, internal interface HTTP is only usable as the destination
for a call. If a call is received on this interface, music on hold, an announcement
or some other spoken information is played from a Web server. The configuration
only makes sense in combination with the innovaphone PBX.
4.2.2.2.2 CGPN/CDPN Mappings
For every interface, it is possible to store so-called CGPN In, CDPN In, CGPN Out
and CDPN Out mappings (Calling Party Number In, Called Party Number In,
Cal-ling Party Number Out, Called Party Number Out), enabling call numbers
and call number formats to be adjusted for incoming and outgoing calls. The call
number formats are as follows:
State
(IP of the SIP provi-
der)
Alias
(PBX user object)
Registration
(IP of the PBX)
For example,
217.10.79.9
(sipgate.de)
H.323 name:E.164 no.
SIPTrunk:8
--> 127.0.0.1
Unknown Unspecified. Number called in outgoing calls. u
