There are totally four groups of acceleration/deceleration time for selection.
Group 1: F0-17 and F0-18;
Group 2: F8-03 and F8-04;
Group 3: F8-05 and F8-06;
Group 4: F8-07 and F8-08;
It can select acceleration/deceleration time via the multifunctional digital input terminals (F4-00
to F4-08).
Group F1 Motor Parameters
F1-00
Motor type selection Factory default value 0
Setup range
0 common asynchronous motor
1 Variable frequency asynchronous motor
2 Permanent magnetic synchronous motor (reserved)
F1-01
Rated power Factory default value model dependent
Setup range 0.4kW ~1000.0kW
F1-02
Rated voltage Factory default value 380V
Setup range 0V~ 440V
F1-03
Rated current Factory default value model dependent
Setup range 0.00A~ 655.35A
F1-04
Rated Frequentcy Factory default value model dependent
Setup range 0.00Hz~ maximum frequency
F1-05
Rated rotation speed Factory default value 1460rpm
Setup range 0rpm ~ 30,000rpm
Caution
1. Please set the parameters according to the nameplate parameters of the motor.
2. It needs accurate motor parameters to ensure the excellent control performance of the
vector control. Accurate parameter identification comes from the correct setting of the
rated motor parameters.
3. To ensure the control performance, please carry out motor con gurations in accordance
with the standard adaptable motor of the inverter. If there is huge difference between the
motor power and the power of standard adaptable motor, the control performance of the
inverter will decrease obviously.
