Appendix MD320/MD320N User Manual
196
Command Word
Address
Command Function
2000
0001
：
Forward operation
0002
：
Reverse operation
0003
：
Forward jog
0004
：
Reverse jog
0005
：
Free stop
0006
：
Speed-down stop
0007
：
Fault reset
Read inverter status :( read-only)
Status Sord Address Status Word Function
3000
0001
：
Forward operation
0002
：
Reverse operation
0003
：
Stop
Parameters locking password checksum: (If the return is the 8888H, it indicates the password
checksum pass)
Password Address Contents of Input password
4000 *****
Parameter locking command :( write-only)
Address of locking
password command
Contents of locking password command
5000 0001
：
lock system command code
Digital output terminal control:
(
write-only)
Address of locking
password command
Contents of locking password command
6000
BIT0
：
DO1 output control
BIT1
：
DO2 DO2 output control
BIT2
：
RELAY1 RELAY1 output control
BIT3
：
RELAY2 RELAY2 output control
BIT4
：
FMR FMR output control
