Inovance MD300 - Physical Dimensions and Mounting Hole Dimensions (MM)

MD320/MD320N User Manual Product Information
29
Model
Mounting Hole
mm
Physical Dimensions mm
Diameter
of
Mounting
Hole mm
Weight
(kg)
A B H H1 W D
MD320NS0.4G
113 172 186 / 125 164 ø5.0 1.1
MD320NS0.7G
MD320NS1.5G
MD320NS2.2G
MD320NT0.7GB
MD320NT1.5GB
MD320NT2.2GB
MD320NT3.7GB
148 236 248 / 160 183 ø5.0 2.5
MD320NT5.5PB
MD320NT5.5GB
MD320NT7.5PB
MD320NT7.5GB
190 305 322 / 208 192 ø6 6.5
MD320NT11PB
*
MD320NT11GB
*
MD320NT15PB
*
MD320NT15GB
*
MD320NT18.5PB
MD320NT18.5G
MD320NT22P
235 447 432 463 285 228 Ø6.5 20
MD320NT22G
MD320NT30P
MD320NT30G
MD320NT37P
MD320NT37G
260 580 549 600 385 265 Ø10 32
MD320NT45P
MD320NT45G
MD320NT55P
MD320NT55G
MD320NT75P
Table 2-4 Physical Dimensions and Mounting Hole Dimensions (mm)
