MD320/MD320N User Manual Parameter Description
123
F5-09
FMP output maximum
frequency
Factory default value 50.0kHz
Setup range 0.1kHz~ 50.0kHz
When the FM terminal is selected as pulse output, it can output maximum frequency of the
pulse.
F5-10
AO1 offset coefcient Factory default value 0.0%
Setup range -100.0% ~ 100.0%
F5-11
AO1 gain Factory default value 1.00
Setup range -10.00~ 10.00
F5-12
AO2 offset coefcient Factory default value 0.00%
Setup range -100.0%~ 100.0%
F5-13
AO2 gain Factory default value 1.00
Setup range -10.00~ 10.00
If “b” represents zero offset, k represents gain, Y represents actual output, and X represents
standard output, the actual output is: Y=kX+b;
AO1 and AO2 zero offset coefcients 100% corresponds to 10V(20mA).
Standard output refers to 0 to maximum analog output corresponding to the output of 0
to10V(20mA).
Setup
value
Function Range
0 Running frequency 0 to maximum output frequency
1 Setup frequency 0 to maximum output frequency
2 Output current 0 to 2 times of the motor rated current
3 Output torque 0 to 2 times of the motor rated torque
4 Output power 0 to 2 times rated power
5 Output voltage
0 to 1.2 times of the rated voltage of
the inverter
6
PULSE input
PULSE input
0.1kHz to 50.0kHz
7 AI1 0V to 10V
8 AI2 0V to 10V/0 to 20mA
9 AI3 0V to 10V
10 Length 0 to maximum setup length
11 Counting value 0 to maximum counting value
12
Communication
setup
