Name Model Function Remarks
Common PG card 1 MD32PG Rotary encoder interface card
15V power supply,
push-pull or
open collector
output encoder is
adaptable
Common PG card 2 MD32PGD
Rotary encoder interface card with
frequency division output
Long cable drive PG MD32PG3
It is applicable to the differential-
mode encoder.
It is applied in
the situation with
synchronous motor
and induction
motor close loop
control
External LED
operation panel
MDKE
External LED display and operation
keyboard
MD series general-
purpose RJ45
interface
External LCD
operation panel
MD32KC
External LCD display and
operation keyboard
RJ45 interface
Parameter copy unit MDCP Parameter copy
MD series general-
purpose RJ45
interface
EPS commercial
power
synchronization
card
MD32EPS EPS mains synchronization
The output voltage
of the inverter is
synchronous with
the mains supply of
the inverter.
Extended cable MDCAB
Standard 8-core network cable,
and it can be c onnecte d with
MDKE, MD32KC and MDCP.
3m are standard.
Rectier unit MFRU
It is used when the inverter shares
the bus and has energy saving
function.
Rotation speed
tracking card
MF32STC1
When the inverter stops driving
the motor and the motor is in
coast to stop status, it can acquire
the rotation speed and rotation
direction through the combination
of t his h a rdw are c i rc u it a nd
software, thus better controlling
the motor.
Add three cables
from U, V and
W output to the
rotation speed
tracking card input.
