Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑68‑
Param
eter
Code
Parameter
Name
Value Default Description
A6‑08 Minimum
input of AI
curve 5
‑10.00 V to A6‑10 ‑10.00 V These parameters define AI curve 5. A6‑08 and A6‑10,
A6‑12 and A6‑14 are interlocked.
A6‑09 Percentage
corresponding
to minimum
input of AI
curve 5
‑100.0% to +100.0% ‑100.0%
A6‑10 Inflection
point 1 input
of AI curve 5
A6‑08 to A6‑12 ‑3.00 V
A6‑11 Percentage
corresponding
to inflection
point 1 input
of AI curve 5
‑100.0% to +100.0% ‑30.0%
A6‑12 Inflection
point 2 input
of AI curve 5
A6‑10 to A6‑14 3.00 V
A6‑13 Percentage
corresponding
to inflection 2
input of AI
curve 5
‑100.0% to +100.0% 30.0%
A6‑14 Maximum
input of AI
curve 5
A6‑12 to 10.00 V 10.00 V
A6‑15 Percentage
corresponding
to maximum
input of AI
curve 5
‑100.0% to +100.0% 100.0%
A6‑24 AI1 jump point ‑100.0% to +100.0% 0.0% This parameter defines the AI1 jump point. If the input
is within the range from A6‑24 ‑ A6‑25 to A6‑24 + A6‑24,
the value of the AI1 jump point (A6‑24) will be output.
A6‑25 AI1 jump
amplitude
0.0% to 100.0% 0.1% This parameter defines the AI1 jump amplitude. If the
input is within the range from A6‑24 ‑ A6‑25 to A6‑24 +
A6‑24, the value of the AI1 jump point (A6‑24) will be
output.
A6‑26 AI2 jump point ‑100.0% to +100.0% 0.0% This parameter defines the AI2 jump point. If the input
is within the range from A6‑26 ‑ A6‑27 to A6‑26 + A6‑27,
the value of the AI2 jump point (A6‑26) will be output.
A6‑27 AI2 jump
amplitude
0.0% to 100.0% 0.1% This parameter defines the AI2 jump amplitude. If the
input is within the range from A6‑26 ‑ A6‑27 to A6‑26 +
A6‑27, the value of the AI2 jump point (A6‑26) will be
output.
