Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑69‑
Param
eter
Code
Parameter
Name
Value Default Description
A6‑28 AI3 jump point ‑100.0% to +100.0% 0.0% This parameter defines the AI3 jump point. If the input
is within the range from A6‑28 ‑ A6‑29 to A6‑28 + A6‑29,
the value of the AI3 jump point (A6‑28) will be output.
A6‑29 AI3 jump
amplitude
0.0% to 100.0% 0.1% This parameter defines the AI3 jump amplitude. If the
input is within the range from A6‑28 ‑ A6‑29 to A6‑28 +
A6‑29, the value of the AI3 jump point (A6‑28) will be
output.
A6‑30 AI automatic
adjustment
curve
Ones position: Point
selection (for settings)
0: Disable
1: Point 1
2: Point 2
3: Point 3
4: Point 4
Tens position: AI channel
selection (for settings)
0: Disable
1: AI1
2: AI2
3: AI3
Hundreds position:
Control function (for
settings)
0: Disable
1: Enable
Thousands position: X‑
point curve (for display)
0: The control function is
disabled or the channel
is not selected.
2: 2‑point curve
4: 4‑point curve
Ten thousands: Reserved
0 ‑
A6‑31 AI1 input 0: Disable
1: Enable
Others: B connector
1 ‑
A6‑32 AI2 input 0: Disable
1: Enable
Others: B connector
1 ‑
A6‑33 AI3 input 0: Disable
1: Enable
Others: B connector
1 ‑
