Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑70‑
Param
eter
Code
Parameter
Name
Value Default Description
A6‑34 AI polarity
selection
Ones position: AI1
0: Normal value
1: Absolute value
2: Opposite to the
normal value
3: Opposite to the
absolute value
Tens position: AI2
0: Normal value
1: Absolute value
2: Opposite to the
normal value
3: Opposite to the
absolute value
Hundreds position: AI3
0: Normal value
1: Absolute value
2: Opposite to the
normal value
3: Opposite to the
absolute value
0 ‑
A6‑35 AI hardware
source
selection
Ones position: AI1 source
0: Hardware sampling
1: Forced value
Tens position: AI2 source
0: Hardware sampling
1: Forced value
Hundreds position: AI3
source
0: Hardware sampling
1: Forced value
0 If the source is set to 0 (hardware sampling), the AI
value is sourced from hardware sampling.
If the source is set to 1 (forced value), the AI value can
be forcibly set through parameters A6‑36 to A6‑38.
A6‑36 AI1 forced
value
‑10.00 V to +10.00 V 0.00 V If the ones position of A6‑35 is set to 1 (forced value),
you can set the AI1 value forcibly through A6‑36.
A6‑37 AI2 forced
value
‑10.00 V to +10.00 V 0.00 V If the tens position of A6‑35 is set to 1 (forced value),
you can set the AI2 value forcibly through A6‑37.
A6‑38 AI3 forced
value
‑10.00 V to +10.00 V 0.00 V If the hundreds position of A6‑35 is set to 1 (forced
value), you can set the AI3 value forcibly through A6‑
38.
A6‑39 High level
judgment
threshold
when AI uses
as DI
5.5 V to 9.0 V 7.0 V This parameter defines the threshold for judging high
level when the AI is used as the DI.
