Advanced Operations
En-61
Operating procedure (➔ page 59)
■ Resolution
` Through:
Select this to pass video through the AV
controller at the same resolution and with no
conversion.
` Auto
:
Select this to have the AV controller
automatically convert video at resolutions
supported by your TV.
` 480p, 720p, 1080i, 1080p
*1
:
Select the desired output resolution.
` 4K:
Select this for an output resolution four times
that of 1080p. Depending on the resolution
supported by your TV, it will result in either 3840
× 2160 or 4096 × 2160 pixels.
` Source:
Select this for an output following the resolution
level set in “Picture Adjust” (➔ page 71).
You can specify the output resolution for HDMI OUT
and have the AV controller upconvert the picture
resolution as necessary to match the resolution
supported by your TV.
Tip
• You can see the picture by pressing Enter to check the
“Resolution” setting for HDMI OUT (excluding “NET”,
“USB” and “BLUETOOTH” input source).
Note
• With some TVs, video signals are processed in the same
way as “Through” when this setting is set to “4K”.
• If the “Monitor Out” setting is set to “HDBaseT(TM)”, this
setting is fixed to “Through”.
• If the “Monitor Out” setting is set to “Both”, this setting is
fixed to “Auto”.
• For optimum video performance, THX recommends using
the HDMI/HDBaseT™ output and setting the video
resolution to “Through”.
*1
When signal is 1080p input at 24 frames per second, it
will be 1080p output at 24 frames per second.
HDMI Input
If you connect a video component to an HDMI input,
you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player
to HDMI IN 2, you must assign “HDMI2” to the
“BD/DVD” input selector.
If you’ve connected your TV to the AV controller with
an HDMI cable/TIA/EIA568B (both ends) and CAT5e
(or higher category) compatible straight cable,
composite video and component video sources can
be upconverted
*
and output by the HDMI/HDBaseT
output. You can set this for each input selector by
selecting the “
-----
” option, but the video signal
coming from the HDMI/HDBaseT output depends on
the assignments of “
Component Video Input
” and
“
Composite Video Input
”. See “The video and audio
signal flow” for more information on video signal flow
and upconversion (
➔
page 20
).
Here are the default assignments.
*1
If you connect your personal computer to
PC IN
(Analog
RGB), you must assign “
-----
” to the “
PC
” input selector.
■ BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
PC, TV/CD, PHONO
` HDMI1, HDMI2, HDMI3, HDMI4, HDMI5, HDMI6,
HDMI7, HDMI8:
Select the input to which the component has
been connected.
` -----:
Output composite video and component video
sources from the HDMI/HDBaseT output. The
video signal coming from the HDMI/HDBaseT
output depends on the assignments of
“Component Video Input” and “Composite
Video Input”.
Each HDMI input cannot be assigned to two input
selectors or more. When HDMI1 - HDMI8 have
already been assigned, you must first set any
unused input selectors to “-----” or you will be
unable to assign HDMI1 - HDMI8 to other input
selectors.
Note
• The assignment of input selector selected for Zone 2
cannot be changed when the “Zone 2 Monitor Out” is set
to “HDBaseT(TM)” (➔ page 60).
• If no video component is connected to the HDMI input (even
if the HDMI input is assigned), the AV controller selects the
video source based on the setting of “Component Video
Input” and “Composite Video Input”.
• When an HDMI IN is assigned to an input selector as
explained here, the same HDMI IN will be set as a priority
in the “Digital Audio Input”. In this case, if you want to use
the coaxial or optical audio input, make the appropriate
selection in the “Audio Selector” setting (➔ page 73).
• Do not assign an HDMI IN to the TV/CD selector while
“HDMI CEC (RIHD)” is set to “On” (➔ page 77), otherwise
appropriate CEC (Consumer Electronics Control) operation
will not be guaranteed.
• If you assign “-----” to an input selector that is currently
selected in “HDMI Through” (➔ page 77), the “HDMI
Through” setting will be automatically switched to “Off”.
•“AUX” is used only for input from the front panel.
Input selector Default assignment
BD/DVD HDMI1
CBL/SAT HDMI2
STB/DVR HDMI3
GAME1 HDMI4
GAME2 HDMI5
PC
HDMI6
*1
AUX Front/MHL (Fixed)
TV/CD -----
PHONO -----
IN
OUT
Composite video,
component video
HDMI
HDMI/HDBaseT
Composite video,
component video
To Next Page
