Advanced Operations
En-62
Operating procedure (➔ page 59)
Component Video Input
If you connect a video component to a component
video input, you must assign that input to an input
selector. For example, if you connect your Blu-ray
Disc/DVD player to COMPONENT VIDEO IN 2, you
must assign “IN2” to the “BD/DVD” input selector.
Here are the default assignments.
■ BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
PC, AUX, TV/CD, PHONO
` IN1, IN2:
Select the input to which the component has
been connected.
` -----:
Output composite video sources from the HDMI/
HDBaseT™ output. The upconverted output
from composite video sources depends on the
assignment of “Composite Video Input”.
Composite Video Input
If you connect a component to a composite video
input, you must assign that input to an input selector.
If you switch the input to “TV/CD” with its default
assignment, the audio of “TV/CD” is output while the
video of the previously-selected source is displayed.
Here are the default assignments.
■ BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
TV/CD, PHONO
` IN1, IN2, IN3, IN4:
Select the input to which the component has
been connected.
` -----:
The composite video is not input.
Note
•“AUX” is used only for input from the front panel.
•“PC” is used only for input from PC IN.
• Using these inputs as audio-exclusive allows you to enjoy
audio and video from separate inputs. Refer to “Playing
Audio and Video from Separate Sources” for details
(➔ page 42).
Digital Audio Input
If you connect a component to a digital audio input,
you must assign that input to an input selector. For
example, if you connect your CD player to the
OPTICAL IN 1, you must assign “OPTICAL1” to the
“TV/CD” input selector.
Here are the default assignments.
■ BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
PC, TV/CD, PHONO
` COAXIAL1, COAXIAL2, COAXIAL3, OPTICAL1,
OPTICAL2:
Select the input to which the component has
been connected.
` -----:
Select if the component is connected to an
analog audio input.
Note
• When an HDMI IN is assigned to an input selector in
“HDMI Input” (➔ page 61), the same HDMI IN will be set
as a priority in this assignment. In this case, if you want to
use the coaxial or optical audio input, make the appropriate
selection in the “Audio Selector” (➔ page 73).
• Supported sampling rates for PCM signals (stereo/mono)
from a digital input (optical and coaxial) are
32/44.1/48/88.2/96 kHz/16, 20, 24 bit.
•“AUX” is used only for input from the front panel.
Input selector Default assignment
BD/DVD IN1
CBL/SAT IN2
STB/DVR -----
GAME1 -----
GAME2 -----
PC -----
AUX -----
TV/CD -----
PHONO -----
Input selector Default assignment
BD/DVD IN1
CBL/SAT IN2
STB/DVR IN3
GAME1 IN4
GAME2 -----
PC PC IN (Fixed)
AUX FRONT (Fixed)
TV/CD -----
PHONO -----
Input selector Default assignment
BD/DVD COAXIAL1
CBL/SAT COAXIAL2
STB/DVR COAXIAL3
GAME1 OPTICAL1
GAME2 -----
PC -----
AUX FRONT (Fixed)
TV/CD OPTICAL2
PHONO -----
To Next Page
