MEDIAJET – Operating instructions V09 Technical data
55
www.integra-biosciences.com
6.2 Petri dish specifications
As there are no official standards for Petri dishes, the actually measured
dimension of the Petri dishes deviate from the nominal dimensions given by the
manufacturer. Thus for an optimal performance of MEDIAJET we recommend
to use dishes as specified in this section which apply to most of the commercially
available dishes. In general we recommend using dishes with ventilation cams
on the inside of the dish lid.
The dish height (1) can vary between 12-25 mm and can be independently set
in the individual dish filling program, as described in chapter “4.4
Adapting a dish
filling program” on page 30.
The lid outer diameter (2) and the ground clearance (3) are critical for an optimal
performance of MEDIAJET and have to be in the range specified in the table
below.
For an updated compatibility list of the Petri dishes tested on MEDIAJET and
recommended by INTEGRA Biosciences please contact our local distribution
partner.
UV lamp
Output 11W (2.1 W UV-C, 253.7 nm)
1 Dish height
2 Lid outer diameter
3 Ground clearance
Manu-
facturer
nominal
size
in mm
Dish
height (1)
in mm
Ground
clearance
(3) in mm
Measured
lid outer
diameter (2)
in mm
MEDIAJET
configuration
90–100 12–25
6 90.8–92.0 90S
91.8–93.0 90 (standard)
93.1–94.5 90L
91.8–93.0 90 (biplate)
55–60
5 58.1–59.5 60 (standard)
56.7–58.1 60S
35 38.0–39.4 35 (standard)
