MEDIAJET – Operating instructions V09 Technical data
57
www.integra-biosciences.com
6.4 Test tube compatibility chart
In order to avoid spillage, INTEGRA BIOSCIENCES recommends to work with
test tubes of an outer diameter fitting the racks as tight as possible. The chart
below lists the maximal test tube diameter compatible with the available racks
and gives a recommendation on the maximal possible variations in size which
ensure an error free dosing process. For test tubes with an outer diameter of 16,
20, and 25 mm which are longer than 150 mm the use of a centering plate is
required. For an overview of the available accessories refer to the next chapter.
Tube Dimensions Rack Type
Max.
outer
diameter
(mm)
Height
(mm)
Test tube
capacity
Part No. Part No.
centring
plate
required
ID of
dispensing
nozzle
(mm)
12.5–13.0 100–120 6 x 15 103 070 - 2–3
15.5–16.0 100–130 5 x 12 103 071 - 2–3
15.0–16.0 130–200 5 x 12 103 071 103 065 2–3
19.5–20.0 100–130 4 x 10 103 072 - 3–4
19.0–20.0 130–200 4 x 10 103 072 103 066 3–4
24.0–25.0 100–130 3 x 8 103 073 - 4
24.0–25.0 130–200 3 x 8 103 073 103 067 4
29.0–30.0 100–130 3 x 7 103 074 - 4
29.0–30.0 130–200 3 x 7 103 074 - 4
