MEDIAJET – Operating instructions V09 Description of the device
11
www.integra-biosciences.com
2.1.2 Turbo mode option
The turbo mode option accelerates the filling process by using a second pump
head installed. This option requires the turbo mode kit (Part No. 103 036)
including:
2.2 Overview of MEDIAJET
Extension pump head (Part No. 171 090)
Tubing set for Turbo mode (Part No. 103 035),
inner diameter 6 mm, length 2.0 m.
1 Carousel
A standard carousel can accommodate
360 Petri dishes divided up into nine
stacks of 40 dishes. One position in the
carousel must be kept free at all times to
enable perfect working of the device.
2 Safety cover
The safety cover from Plexiglas reduces
the penetration of germs from the ambient
air into the filling chamber and protects the
user against UV radiation.
3 Peristaltic pump
4 Operating panel
(see 2.3)
5 Main switch
