Introduction
20 Datasheet, Volume 1
V
AXG
Graphics core power supply.
V
CC
Processor core power supply.
V
CCIO
High Frequency I/O logic power supply
V
CCPLL
PLL power supply
V
CCSA
System Agent (memory controller, DMI, PCIe controllers, and display engine)
power supply
V
DDQ
DDR3 power supply.
VLD Variable Length Decoding.
V
SS
Processor ground.
x1 Refers to a Link or Port with one Physical Lane.
x16 Refers to a Link or Port with sixteen Physical Lanes.
x4 Refers to a Link or Port with four Physical Lanes.
x8 Refers to a Link or Port with eight Physical Lanes.
