Intel Express 460T User Manual

6
CHAPTER 1 Intel Express 460T Standalone Switch Users Guide
Installing a Module
You can install optional modules only in the Module A slot located at the
back of the switch. Use the LEDs on the front of the switch to check the
module’s status.
To install the module in the switch
1 Unplug the power cord from the switch. Remove the panel from the
expansion slot labeled Module A.
2 Align the module with the card guides inside the switch and slide the
module into the slot. Press firmly to connect the module and secure it
with the retaining screws.
3 Plug in the power cord.
Module A slot
1000SX Module or
1000LX Module
100FX Module
1000T Module
