CHAPTER 1 Intel Express 460T Standalone Switch Users Guide
Switch Features
The following diagrams show the major features of the 16-port and 24-port
versions of the 460T Standalone Switches.
12345678
9 10111213141516
MDI
MDI-X
Left
Link = Solid Green
Activity = Blinking Green
Collision = Blinking Orange
Right
10Mbps = Solid Orange
100Mbps = Off
Status
Intel
®
Express 460T Standalone Switch
Status
Module A
Link\Act\Coll
Link\Act\Coll
Port 1 Port 2
12345678
9 10111213141516 1718192021222324
MDI
MDI-X
Left
Link = Solid Green
Activity = Blinking Green
Collision = Blinking Orange
Right
10Mbps = Solid Orange
100Mbps = Off
Status
Intel
®
Express 460T Standalone Switch
Status
Module A
Link\Act\Coll
Link\Act\Coll
Port 1 Port 2
Local Management
AC Input
100-240 VAC
50Hz-60Hz
1.5A max
Console: 9600-8-N-1
EIA 232
MAC Address
009027390008
Module A
• Auto-negotiates speed, duplex, and flow control—10 Mbps or 100 Mbps per port.
• Half-duplex and full-duplex flow control.
• One expansion slot for the optional 100FX, 1000SX, 1000LX, or 1000T module.
• Configure port settings manually through management.
• Access menu-driven Local Management through the serial port or a Telnet session.
• Access the graphic, Web-based, Web Device Manager through a Web browser.
PortPort
LEDs
16-port 460T Switch (Product Code ES460T16)
24-port 460T Switch (Product Code ES460T24)
AC Power
Plug
Back of 16-port and 24-port 460T Switch
Serial
Port
MDI/MDI-X
button
PortPort
LEDs
MDI/MDI-X
button
Module A slotMAC
address
Module LEDs
Module LEDs
Status LED
Status LED
