87
Using Local Management
CHAPTER 5
Local Management
To create a port-based VLAN
1 On the main menu, select Configure VLAN. Note: Make sure the
switch’s current VLAN operation mode is set to port-based VLAN. If
another type of VLAN is running, see “Configure VLAN Operation
Mode” to change the VLAN operation mode.
2 Select Add a Port-based VLAN and press e.
3 Type a name for the new VLAN and press e.
4 Select ports to add to the VLAN by using the z to toggle the
Member field to Yes.
5 Select the APPLY button and press e.
Edit/Delete a Port-based VLAN
Description
Action: Specifies whether to delete a VLAN or to change its port
membership. Press the z to toggle Edit or Delete and then use the
T or S keys to select a VLAN and press e. The DEFAULT_VLAN
cannot be deleted from the switch.
VLAN Name: The names of existing port-based VLANs.
Ports: Total number of member ports in the specified VLAN.
LOCATION
Main Menu
Configure VLAN
Edit/Delete a Port-based VLAN
Edit VLAN
