Technical Information

APPENDIX A

Appendix A

# linkaggr_list={(index “name”, width of the aggregated group, “state”

# index=from 1 to 4 (4=max number of aggregated groups possible)

# name=name of the aggregated group

# width=total port width of aggregated group

# state=”enable” or “disable” (default=disable)

linkaggr_list={(1 “Engineering Server”, 2 “disable”) (2 “Marketing Server”, 3, “enable”)

(3 “3rd Floor Switch”, 2, “enable)}

###### Configure PVID for Untagged Ports #############################################

# pvid_list={(port#, PVIDvalue) (port#, PVIDvalue) ...}

# port#=port attached to device that does not support tags

# PVIDvalue=VID of port to which you want untagged traffic routed

pvid_list={(2, 100) (3, 100) (6, 15)}

###### Create 802.1Q VLAN on the Switch (Static Entries) ###################################

# 802_1q_static_list={(VID, “VLANstring”, M/N U/T,...) (VID, “VLANstring”, M/N U/T,...)}

# M=member port (on ingress)

# N=non member port (on ingress)

# U=untagged device (on egress)

# T=tagged device (on egress)

# Either M or N can be specified for each port; not both

# Either U or T can be specified for each port; not both

802_1q_static_list={(2, “VLAN2”, MT, MU, MT, NT, MT, NU, NT, NU) (10, “VLAN10”, MT, MU,

NT, NT, MT, MU, NT, MU)}

###### GVRP (Dynamic VLAN Registration) ###################################

# gvrp_enabled={port#, port#, ...}

# gvrp_disabled={port#, port#, ...}

# gvrp_enabled=VLAN dynamically registered with the switch

# gvrp_disabled=VLAN not dynamically registered with the switch

gvrp_enabled={1, 3, 5, 7}

gvrp_disabled={2, 4, 6, 8}

Intel Express 460T User Manual
