Intel Express 460T User Manual

44
CHAPTER 4 Intel Express 460T Standalone Switch Users Guide
3 Configure ports for handling untagged traffic.
a From the main Tag-based VLAN page, click Port Settings.
b On the Port Settings screen, you can set port-specific behaviors for
processing VLAN traffic. To configure a specific port, click it in the
faceplate graphic. To configure the same setting across all ports, click
Configure All Ports and Module.
Options include:
• Default Port VID: Sets the port VID (PVID) that will be assigned to
untagged traffic on a given port. For example, if port 10's default PVID
is 100, all untagged packets on port 10 will belong to VLAN 100. The
default setting for all ports is VID 1.
• GVRP: Allows automatic VLAN configuration between the switch
and nodes.
• Ingress filtering: Allows incoming frames belonging to a specific
VLAN to be forwarded if the port belongs to the same VLAN.
Disabling this setting causes all frames to be forwarded, regardless of
the port's VLAN membership.
4 Click Submit.

Intel Express 460T Specifications

General

Brand	Intel
Model	Express 460T
Category	Switch
Language	English
