Chassis Description
6 Intel® Server Chassis SC5300 User Guide
Base Redundant Power Chassis Rear View
TP00540
A
B
C
D
E
F
H
G
A. Removable Power Supply
B. I/O Ports
C. Expansion Slot Covers
D. PCI Add-in Card Panel
E. PCI Card Latch
F. Rear Serial B Connector*
G. ICBM or SCSI Knockout
H. Power Supply Filler Panel
* Items shown may be different in your chassis.
Figure 6. Intel® Server Chassis SC5300 BRP and SC5300 LX Chassis Rear View
