Setting Up the Chassis
Intel® Server Chassis SC5300 User Guide 29
4. Hold PCI add-in board by its top edge or upper corners. Firmly press board into an expansion
slot on the server board (letter “A”). Close back panel PCI Add-in Card Retention Device
(letter “B”).
TP00555
B
A
Figure 38. Installing an Add-in Board
5. Repeat Step 4 until all PCI add-in cards are installed.
