Maintaining Your Server
Intel® Server Chassis SC5300 User Guide 47
7. Loosen thumb screw (letter “A”) securing Power Distribution Board to chassis. Lift Power
Distribution Board off of standoffs (letter “B”) and then remove through back of power supply
cage. You may have to feed the power cables through the power supply cage while removing
the Power Distribution Board.
C
TP00698
A
B
Note: Cables on back of Power Distribution Board not shown to clarify removal process.
Figure 57. Removing Power Distribution Board
