17
Planning Installation
4.2.3 Packing List
Before beginning installation, make sure you have all the included components.
ADU Package
Item Q'ty Size Description
Above Deck Unit (ADU) 1 Radome and Pedestal
BDU Package
Item Q'ty Size Description
Antenna Control Unit (ACU) 1
431 mm x 350 mm x
44.3 mm
Antenna Control Unit (ACU)
Quick Installation Guide (QIG) 1 Installation guide
RF Hazard Sticker 1 Radiation safety distance (12 m) label
Mounting Template 1
Real size drawing of antenna mounting
hole pattern
ACU Rack Mount Bracket 2 For installing ACU to 19-inch rack
Flat Head Screw 10 M4 x 12L
For mounting ACU Rack Mount Bracket
on ACU
AC Power Cord (CEEE7/7) 1 1.5 m ACU power cord (220 V)
Ethernet Cable (RJ45 to RJ45) 1 1 m To connect ACU to PC / network device
RF Cable (F (M) to F (M)) 2 1 m To connect ACU to Modem (Tx / Rx)
Hex Bolt (BUMAX) 5 M8 x 40L
Bolt kit for antenna-deck (mast)
assembly
(1 spare set included)
Flat Washer (BUMAX) 5 M8
Spring Washer (BUMAX) 5 M8
To Next Page
