19
Planning Installation
4.4 Unpacking System Package
Follow the steps for easy and safe unpacking.
The system package consists of two sub-packages that an
ADU Package and a BDU Package.
BDU Package
ADU Package
Figure 7: Unpacking System Package
1. Remove the top cover and take out the BDU package.
AC Power Cord,
Ethernet Cable,
RF Cable
Quick Installation
Guide (QIG),
Antenna Mounting
Template,
RF Hazard Sticker
ACU Rack Mount
Bracket
ACU Unit
ADU/BDU Bolt Kit
Figure 8: Unpacking BDU Package
