6.4 Antenna System Conguration
For the proper operation of the satellite communication system, the required components must be
connected as shown in the gure. Separate purchase of a satellite modem and ship's gyrocompass may be
needed.
Figure 18: Antenna System Conguration
6.4.1 Single Antenna System Conguration
The basic system consists of one VSAT antenna and one ACU. Connect the cables according to the
following conguration.
NOTE
NOTE
The dual antenna system is not congurable with this system.
Above Decks
Below Decks
ACU
Antenna
Modem
(Not supplied)
Tx Rx
Antenna
RF Connector
(Tx, Rx, 48 VDC Power)
iDirect X7 Modem
(OpenAMIP)
AC 100~240V
100~240 VAC
Ship's Gyro
(Not supplied)
LAN
NMEA Input
0183 (GYRO)
Modem
Tx
Modem
Rx
