Intellian v45C User Manual

24
v45C - Maritime VSAT Antenna System
Unit: mm (inch)
Figure 12: Recommended Size of Mast
Ø200.0 (7.87)
Unit: mm (inch) BOW
45˚
Ø110.0 (4.33)
Ø180.0 (7.08)
Gooseneck
228.6 (9)
Antenna Mounting Hole
Ø10.0 (0.39), 4ea
228.6 (9)
Ø380.0 (14.96)
Ø45 (1.77)
Ø22 (0.87)
Ø22 (0.87)
Ø200.0 (7.87)
950.0 (37.40)
500.0 (19.68)
200.0 (7.87)
20 (0.78)
1200.0 (47.24)
Plate Thickness
Min. 5.0 (0.19)
Max. 10.0 (0.39)
Ø380.0 (14.96)
Drain Hole
Ø20.0 (0.78), 1ea
