Installing Above Deck Unit (ADU)
Chapter 5. Installing Above Deck Unit (ADU)
5.1 Antenna Dimensions
Conrm the height and diameter of the antenna unit shown in the following gure before installing it. To
protect the cable connectors on the bottom of radome, the antenna is shipped from the factory with
protective rubber cap on the RF port.
NOTE
NOTE
Position the antenna with the BOW direction parallel to the center line of the ship.
Unit: mm (inch)
Figure 10: Antenna Dimensions
BOW
Direction
627 (24.68)
Ø610 (24.01)
228.6 (9)
BOW
Direction
RF Port
Mouting Hole
Ø
9
(0.35),
4 ea
BOW Mark
BOW
