89
Speciļ¬cation
Antenna Control Unit (ACU)
ACU Size 431 mm x 350 mm x 44.3 mm
ACU Weight 5.2 Kg
LED Indicator
Six LEDs for POWER, INT/SEARCH, TRACKING, LOCK,
SETUP/TEST, ERROR
Ship's Gyrocompass Interface NMEA 0183
PC Interface
Front: Ethernet port, USB (PC, DN: Not working)
Back: RS-232C (57600 bps 8, N, 1)
Modem Interface Ethernet port, RS-232/422, I/O Console
Ethernet port
Front: RJ-45 Management LAN port (1 ea)
Back: RJ-45 LAN port (1 ea)
RF Port
Antenna: N-Type (1 ea)
Modem Tx/Rx: F-Type (2 ea)
Input Power 100 ~ 240 V AC, 50/60 Hz, 1A
