No. Item Description
1
Mediator Setting
The Intellian's new ACU has embedded Dual Antenna Mediator function, which
utilizes to switch between two Intellian VSAT antenna systems simultaneously. When
one antenna is blocked by obstacles or has suddenly lost service, another antenna
will immediately provide the fail-safe operation to maintain the highest levels of
system performance and reliability.
2
Mediator
Sets whether or not to use the dual antenna mediator function.
• Yes: enable the mediator function to use the Dual Antenna System. The
submenu is shown for detailed function settings.
• No: disable the mediator function.
Click the "Apply" button to apply the settings to the system. Then perform the
"iARM Save & Reboot" on page 79.
3
Antenna Active
This function is available in the Primary Antenna's AptusNX when both Primary
Role's ACU and Secondary Role's ACU are connected to the system.
Sets the method for selecting the active antenna. The active antenna (either
primary or secondary antenna) is communicating (Tx/Rx) with a satellite.
• Auto: this method is recommended. Automatically switch-over to the primary
or secondary antenna which is no blockages and no errors.
• Primary: manually switch-over to the primary antenna which is connected to
the modem and the gyrocompass.
• Secondary: manually switch-over to the secondary antenna.
Click the "Apply" button to apply the settings to the system.
Mediator Setting (Optional: For Dual Antenna System)
This function is available when using Dual Antenna System.
1
2
3
4
5
6
7
Primary Antenna's AptusNX View Secondary Antenna's AptusNX View
4
To Next Page
