Intellian v85NX User Manual

103
Specification
Test Intellian Standard
Temperature
(ADE)
Operational IEC-60945 (-25°C to +55°C/Power On)
Survival
IEC-60945
(-40°C to +80°C / Powered On and a non-functional state)
Storage IEC-60945 (-40°C to +85°C/Power off)
Temperature
(ACU)
Operational -15°C to +55°C (IEC-60945)
Survival -25°C to +70°C (IEC-60945)
Storage -40°C to +85°C (IEC-60945)
Wind 56 m/sec (125 mph)
Humidity
IEC-60068-2-30
Upper test Temp.: +40°C (-3), Humidity 98%
Lower test Temp.: +15°C (+3), Humidity 71% ~ 78%
Vibration
Operational IEC-60945
Survival
IEC-60721-3-6 Class 6M3
DNV Standard No. 2.4, Class C
Shock
Operational IEC-60068-2-27 Method Ea 20g, 7 ms
Survival (Transient) IEC-60721-3-6 Class 6M3 type II 30g, 6 ms
Survival (Bump) IEC-60068-2-29 Method Eb 25g, 6 ms
Salt mist
Saline solution : 5 ±1 % NaCl
Storage period: 7 Days (IEC-60945)
Waterproong IPX6 (IEC-60529)
Solar
IEC 60945-Annex B.
Operational +32°C air temperature with the addition of 670 Watt/m solar radiation
Environmental Specication
Antenna Control Unit (ACU)
ACU Size 431mm x 350mm x 44.3mm
ACU Weight 5.2Kg
Display 256x64 Graphic OLED
Key Two Push Keys
LED Indicator Three LEDs for Power, Tracking and Error
USB Port 2ea (front panel), 1ea (rear panel, for Wi-Fi dongle)
Ship's Gyrocompass Interface NMEA 2000, NMEA 0183 (GYRO)
GPS NMEA Out
Serial Interface RS-232C (57600bps 8, N, 1)
Mediator Interface Embedded in ACU, Primary / Secondary control on AptusNX
Modem Interface Ethernet port, RS-232C/422C, I/O Console
Modem Protocol iDirect, Comtech, SatLink, Hughes, GILAT, Newtec, IPSTAR
Ethernet port RJ45, TCP/IP connection
Input power 100 ~ 240 VAC, 50~60Hz, 3A
