WARNING
WARNING
When lifting the antenna using the lifting straps, make sure to remove the securing radome brackets to
separate antenna from the pallet.
4. Check up the condition of lifting strap to make sure the shackles (2EA) are tightened. Re-wrap the
shackles with the existing protection to avoid radome damage.
Lifting Strap
Shackles (2EA)
Placing Antenna on Mast
The Intellian antenna comes with the lifting straps pre-mounted from the factory. Check
the condition of the lifting strap and that the shackle is tightened up. Lift the antenna
above the mast using a crane and carefully put the antenna down on the mast. When
placing the radome, consider that the antenna should be positioned with the BOW
marker aligned as close as possible to the ship's heading.
WARNING
WARNING
The antenna may be subject to swaying motions in windy conditions.
Be careful when handling the antenna.
To Next Page
