Antenna System
Antenna Radome Height 1229 mm (48.38")
Antenna Radome Diameter Ø1131mm (44.52")
Antenna Reector Diameter Ø850 mm (33.46")
Antenna Unit Weight (With Radome) 96 kg (211.6 Ibs)
Platform 3-axis: Azimuth, Elevation, Cross-level
Positioning
3-axis Velocity Mode Servo Control:
Azimuth, Elevation, Cross-Level
Azimuth Range Unlimited
Elevation Range -20° to +115°
Cross-level Range Up to ± 37º
Stabilization Accuracy 0.2° peak mispointing @ max ship motion condition
Motor Brake System Dynamic braking
Ship's motion
Roll ± 25° at 6 second
Pitch ± 15° at 6 second
Yaw ± 8° at 6 second
Turning rate Up to 12°/sec & 5°/sec
RX
Frequency 10.7 ~ 12.75 GHz
Gain 38.9 dBi @ 11.7GHz (without radome)
Tx
Frequency 13.75 ~ 14.5 GHz
Gain 40.7 dBi @ 14.25GHz (without radome)
G/T over Rx Range
at elevation angle > 30 deg.
> 18.3 dB/K @ 12.75GHz (with radome)
Polarization Linear Polarization (Co & Cross-pol)
BUC NJRC 8W (standard), 16W/25W (optional)
LNB Intellian PLL LNB
ACU to ADU Cable (Antenna Cable)
Single 50-ohm coax cable for Rx, Tx, FSK, Reference and Power
from ACU to ADU
Input power 48VDC (max 300W) through Rx/Tx RF Cable
Specification
