Intellian v85NX User Manual

97
Using AptusNX
No. Item Description
4
Modem
Connection
Sets the information for connecting with the modem.
• Modem IP: sets the modem IP address.
• Port: sets the connection Port.
• ID: sets the connection ID.
• Password: sets the connection Password.
• Auto Connect: the enabling auto connect and rebooting the ACU will save
connection data and will auto connect once ACU is powered on next time.
• Last Update Date: displays the last update date and time.
• Connect: displays last updated data and time of the modem data.
• RX SNR: displays the RX SNR data.
5
Beam Selector
This menu can be edited when "iDirect Open AMIP Modem" option is selected in the
"Select Modem" menu.
Selects the target satellite that you want to track.
• Beam List: choose the target satellite in the list.
• Apply: click the "Apply" button to apply the selected beam to the system, it will
switch to the beam desired.
• Lock: within condition given for test or commissioning, if the user wishes to
stay on a selected beam, the user can lock the beam by clicking the "Lock"
button. This will lead modem stays with the user-selected beam.
• Refresh: if you do not want to lock the beam, click the "Reboot" button.
• Refresh: click the "Refresh" button to load the latest satellite list.
6
BUC Status
This function is activated depending on the BUC type.
Displays current BUC status information (BUC Type, BUC S/W Version, Tx Status,
PLL Lock, Temperature, Checksum and Tx Power Level).
• To Refresh BUC information: click the "To Refresh BUC information" button to
update the BUC status information.
7
BUC Setting
This function is activated depending on the BUC type.
Sets the BUC setting options.
• Tx Status: selects whether or not to use the Tx connection (ON or OFF).
• Attenuator (dB): sets attenuation value.
Click the "Apply" button to apply the settings to the system.
8
Newtec Modem
Monitor
This menu can be edited when "Newtec AMIP" option is selected in the "Select Modem"
menu.
Sets the Newtec Modem options.
• dBm: displays the signal level from the Newtec Modem.
• Es/NO: displays the Es/NO value from the Newtec Modem.
• Ntc_s Request Delay Time (ms): sets the period which the system receives the
signal level (dBm) and Es/N0 value from the Newtec Modem.
Click the "Apply" button to apply the settings to the system. Then perform the
"iARM Save & Reboot" on page 79.
