LP600 Users Manual
Rev E, February 2017
Page 13 of 43
Example 2 of correct settings: 4 pad totalizing system using scales only:
Scale ID Number of Scales *Host setting
Scale #1: [] [] []
Scale #2: [] []
Scale #3: [] []
Scale #4: [] []
* Host setting is only available when scale ID is set to ‘01’
Serial Output Setup
This setup is not necessary with a typical LP600 system. There are three different
serial output modes for the LP600, “on-demand”, “continuous”, and “accumulating
print”. The rest of this section provides more information on these modes.
To setup the serial output mode: Press the PRINT/ACCUMULATE and ZERO
buttons simultaneously until the display shows “.”, Press the PRINT/
ACCUMULATE button to scroll through the menu (12 times) until the display shows
“”. Press the PRINT/ACCUMULATE button once to display setting number. Set
print mode to the number of the print mode wanted by using the LOCAL/TOTAL button
to increment and the ZERO button decrement the number. .
Accumulating Print Standard
Note: For best results, only set one scale to ‘, ‘ or ‘. This should also be the
scale you are printing from. ‘’ is the default setting.
Press the PRINT/ACCUMULATE button. Now the display will display “”. Press
the PRINT/ACCUMULATE button to change the baud rate set, press the LOCAL/
TOTAL or the ZERO button to cycle through the baud rates available. The baud rates
available are: 1200, 2400, 4800, 9600, 19200, 38400, 57600, and115200. When the
desired baud rate is displayed, press the PRINT/ACCUMULATE button. The baud rate
only needs to be set on the scale doing the printing. The settings are saved once
PRINT/ACCUMLATE is pressed to advance the menu, and the scale can then be
turned off to exit the Mode Menu.
On-Demand
The weight is transmitted every time the PRINT/ACCUMULATE key is pressed.
Press PRINT/ACCUMULATE to print either the local or total weight (depending
on the local/total setting of the scale). This is the default print mode.
