LP600 Users Manual
Rev E, February 2017
Page 40 of 43
failure of the cell or lead; you are typically looking for an open or a short when using this
check.
Calibration “Step” codes
Enter Cal Mode # After “” in Cal Menu
Advance through normal calibration menu.
Advance to weight calibration
Enter corner calibration. (Also set the number of load cell inputs
here.)
Enter Mode menu. (the same menu that is entered if the cal
strap is in the Run position)
Angle display diagnostic.
Individual cell read diagnostic. Next enter specific load cell
number 1-8.
Raw Counts display diagnostic
Constant power to all load cells diagnostic
Corner adjust cell 1-8. (Example: 202 will enter mode to adjust
cell #2).
Restore all radio settings to defaults (CH = 1, Network ID =
8000, Encryption = 8000. Display will then show ‘save’ if
successful, or “” if there is no radio installed or some
other radio failure.
Default and save all settings (Leave calibration and cornering
untouched)
Default and save corner compensation to nominal values
Default and save all board memory (settings, calibration, and
corners)
